Prices starting at: $48,200
View photos, watch videos and get a quote on a new 2026 GMC Sierra 3500 HD in Carrollton, TX.
- Body Exterior
- Rear cargo : tailgate
- Power door mirrors
- Heated door mirrors
- Turn signal indicator mirrors
- Bumpers : chrome
- Rear step bumper
- Trailer hitch
- Trailer sway control
- Hitch Class : IV
- Powertrain
- Engine liters : 6.6L
- Compressor : Not Available
- Cylinder configuration : V-8
- Horsepower : 401hp @ 5,200RPM
- Torque : 464 lb.-ft. @ 4,000RPM
- Number of valves : 16
- Variable valve control
- Engine location : front
- Hybrid electric powertrain type : none
- Hybrid traction battery type : none
- Electric motor horsepower : none
- Hybrid system net power : none
- Recommended fuel : Regular gasoline
- Transmission : 10 speed automatic
- Mode select transmission
- Manual-shift auto
- Drive type : rear-wheel
- Fuel tank capacity : 36.0gal.
- Rear locking differential
- Hybrid system combined power torque : none
- Electric motor 1 torque : none
- Standard fuel economy fuel type : gasoline
- Warranty
- Basic warranty : 36 months/36,000miles
- Powertrain warranty : 60 months/60,000miles
- Corrosion perforation warranty : 72 months/100,000miles
- Roadside assistance coverage : 60 months/60,000miles
- Maintenance warranty : 12 months/12,000miles
- Suspension/Handling
- Front wheel independent suspension
- Front anti-roll bar
- Power steering
- Front tires : 275/70SR18.0E
- Rear tires : 275/70SR18.0E
- Single rear wheels
- Wheel size : 18"
- Tires : all-terrain
- Specs and Dimensions
- Engine displacement : 6.6 L
- Engine torque : 464 lb.-ft. @ 4,000RPM
- Engine bore x stroke : 103.3mm x 98.0mm (4.07" x 3.86")
- Compression ratio : 10.80 to 1
- Payload : 2,079kg (4,583lbs)
- Curb weight : 2,871kg (6,329lbs)
- GVWR : 4,967kg (10,950lbs)
- Towing capacity : 6,577kg (14,500lbs)
- Exterior length : 6,002mm (236.3")
- Exterior body width : 2,079mm (81.8")
- Exterior height : 2,056mm (80.9")
- Wheelbase : 3,607mm (142.0")
- Turning radius : 7.1m (23.5')
- Front legroom : 1,131mm (44.5")
- Front headroom : 1,095mm (43.1")
- Front hiproom : 1,547mm (60.9")
- Front shoulder room : 1,678mm (66.1")
- Entertainment Features
- AM/FM radio
- Premium audio system : GMC Infotainment System
- Speakers : 2
- Turn-by-turn navigation directions : OnStar Turn-by-Turn Navigation
- Wireless phone connectivity
- 1st row LCD monitors : 1
- Primary LCD size : 7.0"
- Smart device integration
- Lighting, Visibility and Instrumentation
- Fully automatic headlights
- Delay-off headlights
- Auto high-beam headlights
- Variably intermittent wipers
- Front reading lights
- Appearance : analog
- Tachometer
- Voltmeter
- Oil pressure gauge
- Compass
- Outside temperature display
- Low tire pressure warning
- Trip computer
- Lane departure : warning
- Exterior parking camera rear
- Safety and Security
- Forward collision : mitigation
- 4 wheel disc brakes
- ABS brakes
- Brake assist
- Dual front impact airbags
- Dual front side impact airbags
- Overhead airbag
- Occupant sensing airbag
- Panic alarm
- Perimeter/approach lights
- Ignition disable
- Electronic stability
- Traction control
- Front pedestrian detection : prevention
- Seats and Trim
- Max seating capacity : 3
- Front seats : bench
- Front center armrest : w/storage
- Seat Upholstery : vinyl
- Off-Road Capability
- Ground clearance (min) : 285mm (11.2")
- Convenience Features
- Air conditioning
- Speed control
- Power windows
- 1-touch down
- 1-touch up
- Remote keyless entry
- Proximity key : push button start only
- Illuminated entry
- Tilt steering wheel
- Passenger vanity mirror
- Emergency communication system : OnStar Services capable
- Front beverage holders
- Overhead console
- Driver door bin
- Passenger door bin
